Specifications:

• Measurement Range:

  • Sphere (S): –25.00 to +22.00 D (0.01/0.06/0.12/0.25D Step)

  • Cylinder (C): 0 to ±10.00 D (0.01/0.06/0.12/0.25D Step)

  • Axis: 0°–180° (1° increments)

• Spherical Power (Contact Lens): ±20.00 D (0.1 mm)

• ADD Power: 0–9.99 D (0.01 D step)

• Prism Power: 0–15 Δ (0.01 Δ step)

• Applicable Lenses: φ10 mm–φ90 mm dia. ≤ 20 mm center thickness

• PD Measurement: 45–82 mm

• Power Supply: DC 12V, 4.5A

• Display: 7-inch TFT Touch Screen

• Printer: Thermal Printer

• Weight: 23.5 kg

• Usage: Qualitative eye power measurement for optical and ophthalmic use.
